Beschrijving
Camera | Aantal beeldsensoren: | 1 | |
Beeldsensor: | 1/2.8 | ||
CMOS: | Progressive Scan CMOS | ||
Aantal pixels: | 1920 x 1080 | ||
Minimale verlichting sterkte (in kleur): | 0.005 Lux | ||
Minimale verlichting sterkte (LED aan (zwart/wit)): | 0 Lux | ||
Verlichting: | IR | ||
LED afstand: | tot 30m | ||
LED Aan/Uit (Dag/Nacht): | Auto/Handmatig | ||
Sluitersnelheid: | 1/3 s ~ 1/100,000 s | ||
Ruisonderdrukking: | 3DNR | ||
Lens | Lens type: | Vaste lens | |
Iris: | Vaste Iris | ||
Brandpuntsafstand: | 2.8mm | ||
Maximale opening: | F1.6 | ||
Horizontale openingshoek: | 108° | ||
Focusbediening: | Geen | ||
Camera positioneren | Pan: | 0° ~ 355° | |
Tilt: | 0° ~ 75° | ||
Rotate: | 0° ~ 355° | ||
Video | Stream mogelijkheid: | 3 streams | |
Video compressie: | H.264 | ||
H.264 + | |||
H.265 | |||
H.265 + | |||
MJPEG | |||
Beelden per seconde (Hoofdstream): | 25fps @1920 x 1080 | ||
2de stream: | 25fps @640 x 480 | ||
3de stream: | 25fps @1920 x 1080 | ||
Bitrate: | 32 Kbps to 16 Mbps | ||
Dag/Nacht: | Auto (filter) | ||
BLC mode: | BLC | ||
HLC | |||
WDR(120dB) | |||
Weergave spiegelen (Mirror): | Ja | ||
Bewegingsdetextie: | Aan/Uit | ||
Interessant gebied (ROI): | Aan/Uit | ||
Slimme Functies: | Face Detection | ||
Intrusion Detection | |||
Line Crossing | |||
Object Removal Detection | |||
Unattended Baggage Detection | |||
Privacy-maskering: | Ja | ||
Audio | Ingebouwde microfoon: | Nee | |
Audio ingang: | Nee | ||
Audio Uitgang: | Nee | ||
Netwerk | Ethernet: | 1 RJ45 10M/100M self-adaptive Ethernet port | |
Interoperabiliteit: | ISAPI | ||
ONVIF PROFILE G | |||
ONVIF PROFILE S | |||
Opslag optie SD-kaart: | Ja | ||
Opslag Capaciteit SD-kaart: | 128 GB | ||
Web Browser Ondersteuning: | Internet Explorer (IE) | ||
Google Chrome | |||
Mozilla FireFox | |||
Apple Safari | |||
Mobiele ondersteuning: | Android | ||
IOS | |||
Interface | RS-485: | Nee | |
Alarm: | Nee | ||
Elektrisch | Voeding: | 12V DC | |
PoE (Type IEEE 802.3af) | |||
Max Verbruik: | 6.5W | ||
Omgeving | Werktemperatuur: | -30°C ~ +60°C | |
Waterdichtheid: | IP67 | ||
Vandaalbestendig: | IK10 | ||
Constructie | Diameter | Ø111mm | |
Hoogte | 82.4mm | ||
Gewicht: | 0.5 Kg |
