Beschrijving
Camera | Aantal beeldsensoren: | 1 |
Optisch/Termisch: | Optisch | |
Beeldsensor: | 1/1.8 | |
CMOS: | Progressive Scan CMOS | |
Aantal pixels: | 1920 x 1080 | |
Minimale verlichting sterkte (in kleur): | 0.002 Lux | |
Minimale verlichting sterkte (LED aan (zwart/wit)): | 0 Lux | |
Verlichting: | IR | |
LED afstand: | tot 30m | |
LED Aan/Uit (Dag/Nacht): | Auto/Handmatig | |
Sluitersnelheid: | 1s ~ 1/100.000s | |
Ruisonderdrukking: | 3DNR | |
Video Uitgang: | Ja | |
Video Uitgang Opmerking: | 1Vp-p composite output (75 Ω/CVBS) | |
Lens | Lens type: | Motorzoomlens |
Iris: | Vaste Iris | |
Brandpuntsafstand: | 2.8mm ~ 12mm | |
Maximale opening: | F1.2 | |
Horizontale openingshoek: | 39° ~ 103° | |
Verticale openingshoek: | 21.9° ~ 54.2° | |
Focusbediening: | Auto/Handmatig | |
Camera positioneren | Pan: | 0° ~ 355° |
Tilt: | 0° ~ 75° | |
Rotate: | 0° ~ 355° | |
Video | Stream mogelijkheid: | 5 streams |
Video compressie: | H.264 | |
H.264 + | ||
H.265 | ||
H.265 + | ||
Beelden per seconde (Hoofdstream): | 50fps @1920 x 1080 | |
2de stream: | 25fps @704 x 576 | |
3de stream: | 25fps @1920 x 1080 | |
4de stream: | 25fps @1920 x 1080 | |
5de stream: | 25fps @704 x 576 | |
Bitrate: | 32 Kbps ~ 16 Mbps | |
Dag/Nacht: | Auto (filter) | |
Kleur | ||
Zwart/Wit | ||
BLC mode: | BLC | |
HLC | ||
WDR(140dB) | ||
Bewegingsdetextie: | Aan/Uit | |
Interessant gebied (ROI): | Aan/Uit | |
Slimme Functies: | Intrusion Detection | |
Line Crossing | ||
Object Removal Detection | ||
Region Entrance Detection | ||
Region Exiting Detection | ||
Unattended Baggage Detection | ||
Elektronische Beeld Stabilisatie(EIS): | Ja | |
Defog: | Ja | |
Privacy-maskering: | Ja | |
Audio | Ingebouwde microfoon: | Nee |
Audio ingang: | Ja | |
Audio Uitgang: | Ja | |
Netwerk | Ethernet: | 1 RJ45 10M/100M/1000M Ethernet port |
Interoperabiliteit: | ISAPI | |
ONVIF PROFILE G | ||
ONVIF PROFILE S | ||
SDK | ||
Opslag optie SD-kaart: | Ja | |
Opslag Capaciteit SD-kaart: | 256 GB | |
Web Browser Ondersteuning: | Internet Explorer (IE) | |
Google Chrome | ||
Mozilla FireFox | ||
Apple Safari | ||
Mobiele ondersteuning: | Android | |
IOS | ||
Interface | RS-485: | Nee |
Alarm: | Ja | |
Aantal kanalen in: | 1x | |
Aantal kanalen uit: | 1x 24 VDC 1A of 110 VAC 500 mA | |
Elektrisch | inclusief voeding: | Nee |
Voeding: | 12V DC | |
PoE +(Type IEEE 802.3at) | ||
Max Verbruik: | 17W | |
Voeding uitgang: | 12 VDC, max. 200mA | |
Omgeving | Werktemperatuur: | -30°C ~ +60°C |
Waterdichtheid: | IP67 | |
Vandaalbestendig: | IK10 | |
Constructie | Materiaal | Aluminium |
Diameter | Ø162mm | |
Hoogte | 140.3mm | |
Gewicht: | 1.45 Kg |
