Technische specificatie |
Ethernet poort 16x 10/100/1000 Base-T (PoE) |
|
RS232 1 console port |
|
PoE stroomverbruik Poort 1 en poort 2 ondersteunen Hi-PoE 60W |
|
PoE Protocol IEEE802.3af, IEEE802.3at, Hi-PoE |
|
ePoE yes |
|
Switching Capacity 8.8Gbps |
|
Packet Forwarding Rate 5.36Mbps |
|
Packet Buffer Memory 2.75Mb |
|
Toepassingsvochtigheid 5% ~ 95% |
|
Voeding AC100-240V, 50/60Hz, 6A, netsnoer inbegrepen |
|
Bescherming tegen bliksem Common Mode 2KV |
|
Werktemperatuur -10°C ~ 55°C |
|
Afmetingen (LxBxH) |
Algemeen |
System Username / password: admin/admin |
|
PoE Budget Totaal≤240W |
|
MAC Table 4K |
|
NTP Support |
|
DHCP Support DHCP client |
|
VLAN Port-based VLAN |
|
Poort Aggregation Manual aggregation/LACP |
|
Mirroring veel-op-één Port Mirroring |
|
Flow Control Half-duplex based on back pressure type control; Full duplex based on PAUSE frame |
|
Multicast IGMP Snooping v1/v2 |
|
Security Features Users management, SSH, HTTPS, SNMP v1/v2/ v3, ROMN, ACL, IP source guard, ARP inspection, 802.1x, loop protection |
|
Spanning tree Support STP/RSTP |
|
LLDP Support |
|
MAC Table Support MAC address table configuration |
|
QoS Support QoS base on CoS/DPL/PCP/DEI |
|
Network Management WEB(http protocol), serial, SNMP |
Kabel (m) |
Bandbreedte (Mbps) PoE (W) Hi-PoE (W) |
100 |
100 25.5 53 |
200 |
100 25.5 33 |
300 |
100 19 19 |
400 |
10 17 17 |
500 |
10 13 13 |
800 |
10 7 7 |
